Renderer process

Green : pics components

  • App is the entry component of the app, he includes all the vue.js app and all the components.
  • FirstStart displays the welcome page when we start PICS for the first time
  • ConfigureApp displays buttons to select library folder, and start the importation.
    This component interact with the main process via ipc. Event sender : openFolderDialog, startImportingPhotos. Events listener : dialogFilePath, inportingPhotosFinish.
  • Home displays the home page of the app
    • PicsNav the nav bar, with the search field and all research filters.
      This component interact with the main process via ipc. Event sender : searchPics.
    • PicsAside displays the tree view and the "update library" button.
      This component interact with the main process via ipc. Event sender : updatePicsLibrary, getLibraryTree. Events listener : picsLibraryUpdated, libraryTree.
    • PicsMain displays all the pics, separated by event titles.
      This component interact with the main process via ipc. Event sender : getLibraryTree. Events listener : libraryTree.
      • PhotoEvent displays the event title.
      • PhotoCard displays the picture and his name with a hover effect.
  • PicsDetails displays a big overview of the picture
    • PicsMetas displays fields to edit picture metadatas
      This component interact with the main process via ipc. Event sender : editPicsDatas. Events listener : picsDetailsUpdated.

Blue : element-ui components

  • el-tree element component to display a tree view component specs.
  • el-date-picker displays a input field, with a full date-picker on click component specs.
  • el-tags displays a tag list and fields to add tag to the list component specs.

In the app we use other element-ui components (like : el-button, el-row, el-col, el-input), because their really simple components, and used many times in the app, we decided to not show it in the top diagram. You found all the element-ui ocmponents here

Orange : router

  • vue-router this component display the right child component, according to the current route used :
    • / => Home
    • /picsDetails => PicsDetails
    • /firstStart => FirstStart
    • /configure => ConfigureApp

Red : vuex state

The vuex state defines global datas, accesible by all the components.

  • editedPics property store the current edited picture data
